Home › GMC › 1997 › Jimmy 4D Utility, AWD › Repair and Diagnosis › Engine Performance › System › Connector Terminal Identification › C100 To C603 › C425

C100 To C603: C425

Fig 1: C415 - 3-Pin Connector, Black
G00167691Courtesy of GENERAL MOTORS CORP.
