Removal Procedure

Raise the vehicle.
Remove the wiring harness connector from the KS (2).
Remove the KS (2) from the engine block (1).

Fig 1: Knock Sensor & Harness Connector (2)
Courtesy of GENERAL MOTORS CORP.
