Installation Procedure

WARNING: This page is about a different car, the 2003 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.

Install the license plate lamp (1) to the liftgate (2).

Fig 1: Installing License Lamp
Courtesy of GENERAL MOTORS CORP.
Install the license plate lamp bulb, turning clockwise.
Install the license plate lamp electrical connector.
Install the trim panel service hole cover. Refer to TRIM PANEL REPLACEMENT - LIFT GATE .
Close liftgate.
