Installation Procedure

WARNING: This page is about a different car, the 2004 Pontiac Vibe. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Loosen/Tighten Mounting Bolts

Courtesy of GENERAL MOTORS CORP.

IMPORTANT: Before installing the hood, be sure to apply anti-corrosion treatment to the hood and hood hinge mating surfaces. Refer to Anti-Corrosion Treatment and Repair in Paint/Coatings.

Install the hood (1) with the aid of a helper to the hood hinges (3), aligning the mating marks. Secure the hood with 2 mounting bolts at each hinge. Do not tighten fully.

Fig 2: Windshield Washer Nozzles And Supply Hose

Courtesy of GENERAL MOTORS CORP.

Install the windshield washer nozzles (2) and supply hose (1) to the hood (3).

Fig 3: Hood Components

Courtesy of GENERAL MOTORS CORP.

Reposition the hood insulator (1) and secure with the 2 plastic retainers (3).

Fig 4: Loosen/Tighten Mounting Bolts

Courtesy of GENERAL MOTORS CORP.

Remove the protective covers from the front fenders (2).
Adjust the hood if necessary. Refer to Hood Adjustment .
