Removal Procedure

  1. Remove the door trim panel. Refer to TRIM PANEL REPLACEMENT - SIDE FRONT DOOR .
  2. Remove the inside door handle rods.
  3. Remove the inside door handle retaining rivets.
  4. Remove the inside door handle from the door by sliding the handle rearward.
    Fig 1: Removing Front Inside Door Handle From Door By Sliding Handle Rearward
    G01477731Courtesy of GENERAL MOTORS CORP.
