Fastener Specifications
Body Control Module Bracket
| Callout | Component Name [Component Quantity] | Single Use Fastener/Component | Thread Locking Adhesive Required | Specification | Procedure |
|---|---|---|---|---|---|
| Metric (English) | |||||
| 1 | Video Processing Module Bracket Bolt [3x] | - | - | 2.5 N.m (22 lb in) | Body Control Module Replacement |
