Repair Procedures: Inspection

Measure the primary coil resistance between terminals (1) and (2).

Fig 1: Measuring Primary Coil Resistance Between Terminals (1) And (2)
Courtesy of HYUNDAI MOTOR AMERICA

Standard Value: 10 MΩ or more
