Monitor Current Data

  1. Ignition "OFF"
  2. Connect GDS to Data Link Connector (DLC).
  3. Ignition "ON" & Engine "OFF"
  4. Monitor following parameters in "Current Data" of CLU with GDS.

    Specification:  Refer to the illustration below

G15568211Courtesy of HYUNDAI MOTOR AMERICA
