| Rated voltage |
13.5V, 150A |
| Speed in use |
0 - 18,000 rpm |
| Pin |
1 |
| Voltage regulator |
IC Regulator built in type |
Default regulated voltage
(V) [COM terminal] |
14.39 - 15.43 [-35°C (31°F)] |
| 14.15 - 14.95 [25°C (77°F)] |
13.23 - 14.49
[140°C (284°F)] |
| Pully Type |
OAP |
