Repair Procedures: Removal

  1. Disconnect the negative (-) battery terminal.
  2. Remove the tailgate back panel.

    (Refer to Body - "Tailgate Back Panel") - "LIFTGATE BACK PANEL "

  3. Loosen the mounting screws and remove the rear camera (A).
G16778295Courtesy of HYUNDAI MOTOR AMERICA
