Diagnostic Aids
An intermittent may be caused by poor connection, rubbed through wire insulation or wire broken inside insulation. Inspect ECM harness connector for backed out terminals, improper mating, broken locks, improperly formed or damaged terminals, poor terminal to wire connection and damaged harness. If code is intermittent, see TESTS W/O CODES article.
