A/C Compressor Thermal Protector Replacement

Remove the bolt, the ground terminal (A) and the holder (B). Disconnect the field coil connector (C), then remove the thermal protector (D).

Fig 1: Removing Ground Terminal And Holder
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Replace the thermal protector (A) with a new one, and apply silicone sealant (B) to the bottom of the thermal protector.

Fig 2: Applying Silicone Sealant To Bottom Of Thermal Protector
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Install the protector in the reverse order of removal.
