Tailgate Support Strut Replacement

WARNING: This page is about a different car, the 2006 Honda Odyssey and 2005 Honda Odyssey. However, it is still accessible from the selected car via links, so may be relevant.

With the help of an assistant, use a flat-tip screwdriver (A) to pry the support strut clips (B) from each end of the support strut (C) at the tailgate and body, then release the support strut from the pivot bolts (D). Do not remove the clips from the support strut.

Fig 1: Prying Support Strut Clips From End Of Support Strut Using Flat-Tip Screwdriver
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Set the clips (A) to the original position, then reattach the support strut (B) on the pivot bolts (C) by pushing the support strut onto the pivot.

Fig 2: Setting Clips And Reattaching Support Strut On Pivot Bolts
Courtesy of AMERICAN HONDA MOTOR CO., INC.
