Front Splash Shield Replacement

WARNING: This page is about a different car, the 2006 Honda Odyssey and 2005 Honda Odyssey. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

Take care not to scratch the body.
Put on gloves to protect your hands.

From under the front bumper (A), remove the clips (B, C, D) securing the front bumper, front bumper air spoiler (E), front splash shield (F), and front inner fender (G) on the front suspension subframe and body.

Fig 1: Removing Clips Securing Front Bumper
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the front splash shield, and release the hooks (H), then remove the air spoiler from the splash shield.
Install the splash shield in the reverse order of removal, and note these items:
- Check the clips for damage or stress-whitening, and replace them with new one.
- Push the clips into place securely.
