Audio Unit

Turn the rear entertainment system ON.
- After the main power switch VOL PUSH PWR (A) is turned ON, push REAR PWR switch (B) to turn the rear system ON. To turn the rear system OFF, push REAR PWR, and to turn the whole system OFF, push VOL PUSH PWR.

  Fig 1: Identifying VOL PUSH PWR & REAR PWR Switches
  Courtesy of AMERICAN HONDA MOTOR CO., INC.
Using the selector knob
- Turn left select the front controls (Audio).
- Turn right to select the rear controls (After rear operation is finished, selector will automatically return to the front control in 10 seconds).

  Fig 2: Using The Selector Knob
  Courtesy of AMERICAN HONDA MOTOR CO., INC.
Rear Control enable/disable
- By pushing the selector knob, the driver can prevent the rear passengers from operating the system. Each push of the selector knob cycles the switch between ON-OFF (Rear Control Enable/Rear Control Disabled). When rear operation is prohibited, the LCD on the audio unit displays RR CONT OFF.

  Fig 3: Identifying RR CONT Display
  Courtesy of AMERICAN HONDA MOTOR CO., INC.
Viewing the twin displays
- The two displays indicate the status of the front (A) and rear (B) systems.

  Fig 4: Viewing The Twin Displays
  Courtesy of AMERICAN HONDA MOTOR CO., INC.
Rear speaker automatic OFF function
- By turning the rear speaker OFF you can reduce the interference between the front source and the rear source (Headphone). The speaker will be turned ON/OFF automatically when the front and rear have different sources selected. When the rear speaker is in the OFF mode, the LCD display on the audio unit displays RR SP OFF.
Fig 5: Identifying Rear Speaker Off Display
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Rear Controller

Using the control switch from the rear seat
- With Rear Power ON the rear passenger can control the functions, unless the rear control has been turned off by the front user.
Fig 6: Using The Control Switch From The Rear Seat
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Wireless Remote Control

Remote control switch use and function
- With Rear Power ON and rear control enabled, the rear passengers can control the functions with the remote, except volume.
Fig 7: Using Remote Control
Courtesy of AMERICAN HONDA MOTOR CO., INC.
