Navigation Unit Removal/Installation

Slide the passenger's seat (A) to the rear.

Fig 1: Sliding The Passenger's Seat To The Rear
Courtesy of AMERICAN HONDA MOTOR CO., INC.
Remove the navigation unit bracket (B) from the passenger's seat.
Remove the bracket from the navigation unit (C).
Install in the reverse order of removal.
