J35A6 Engine

  1. Remove the steering gear box heat shield (A).
    Fig 1: Steering Gear Box Heat Shield With Torque Specifications
    G05522877Courtesy of AMERICAN HONDA MOTOR CO., INC.
  2. Support the engine with a jack and a wood block under the oil pan.
  3. Remove the rear engine mount (B).
  4. Install the rear engine mount in the reverse order of removal.
