Shift Lever Knob Replacement

NOTE:
  • Refer to SHIFT LEVER DISASSEMBLY/REASSEMBLY  as needed during the following procedures.
  • Make sure not to get any silicone grease on the terminal part of the connectors and switches, especially if you have silicone grease on your hands or gloves.
  1. Remove the left center console panel (see DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION ).
  2. Shift the shift lever to N.
  3. Disconnect the D3 switch connector (A).
    Fig 1: Identifying D3 Switch Connector
    G05961905Courtesy of AMERICAN HONDA MOTOR CO., INC.
  4. Remove the screws (A), and remove the shift lever knob (B) from the shift lever.
    Fig 2: Identifying Shift Lever Knob & Screws
    G05961906Courtesy of AMERICAN HONDA MOTOR CO., INC.
  5. Apply silicone grease to the top of the shift lever rod (A).
    Fig 3: Shift Lever Rod With Torque Specifications
    G05961907Courtesy of AMERICAN HONDA MOTOR CO., INC.
  6. Install the new shift lever knob (B).
  7. Secure the shift lever knob with the new screws (C).
  8. Connect the D3 switch connector (A).
    Fig 4: Identifying Shift Lever Knob & Screws
    G05961908Courtesy of AMERICAN HONDA MOTOR CO., INC.
  9. Install the the left center panel (see DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION ).
