With Security

  1. Remove the front bulkhead cover (see FRONT BULKHEAD COVER REPLACEMENT ).
  2. Disconnect the 2P connector (A) from the security hood switch (B).
    Fig 1: Identifying Security Hood Switch With Connector
    G06968709Courtesy of AMERICAN HONDA MOTOR CO., INC.
  3. Check for continuity between the terminals in each switch position according to the table.
    Fig 2: Security Hood Switch Connector Continuity Chart
    G06968710Courtesy of AMERICAN HONDA MOTOR CO., INC.
  4. If the continuity is not as specified, the security hood switch is faulty; replace the hood latch (see HOOD LATCH REPLACEMENT ).
