How To Check the Audio System Condition

WARNING: This page is about a different car, the 2011 Honda Pilot, 2010 Honda Pilot, and 2009 Honda Pilot. However, it is still accessible from the selected car via links, so may be relevant.

The audio system has a self-diagnostic function to help find problems with the audio system. To run the self-diagnostic function, do the following:

NOTE:

Not all self-diagnostic functions appear on all models.
There may be other self-diagnostic functions that are for factory use only.
The self diagnostic function does not find every problem with the audio system. Check any official Honda service website for more information about the audio system.

Turn the ignition switch to ON (II).
Make sure the audio system is turned off.
Push and hold the preset No. 1 and No. 6 buttons.
While holding the buttons, push the VOL PUSH PWR knob to ON.
Release the buttons and the self-diagnostic function begins.

Fig 1: Identifying Audio System Serial Number Location
Courtesy of AMERICAN HONDA MOTOR CO., INC.
When you are in the self-diagnostic mode, pressing a preset button starts the diagnostic mode that is assigned to that preset button.
NOTE: Any other diagnostic screens shown are for factory use only.

No. 2 button

Audio button, knob, and audio remote switch detection: Allows individual manual selection of all audio panel knobs, buttons, and remote switches to verify if they are functional. When properly detected, the applied knob button, or audio remote switch name and/or value will be displayed. To exit this mode, go to step 7. Once you exit this test, you must start again at step 1.

No. 3 button

Entire LCD lighting/light-out mode: Turns on/off the entire LCD to show the presence or absence of an LCD segment.

No. 4 button

Duty indication mode (for the Illumination dim): Indicates the duty for the Illumination dim when the dash lights are on.

No. 5 button

Vehicle speed pulse (VSP) indication mode: Indicates the vehicle speed pulse.

FM button (Push and hold 5 sec.)

Reception level indication mode: Indicates the reception level (dB). When entering the reception level check mode, the AM/FM or FM button is used to change the S-METER, OFFSET, MP and USN (A/I).

Canceling the Self-diagnostic Function
To end the self-diagnostic function, turn the audio unit off or turn the ignition switch to LOCK (0).
