Section 352 (HVAC Systems - Automatic): Specifications
WARNING: This page is about a different car, the 2003 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
FASTENER TIGHTENING SPECIFICATIONS
| Application |
Specification |
| Metric |
English |
| Blower Motor Control Processor Screws |
2 N.m |
18 lb in |
| Mode Actuator Screws |
1.4 N.m |
12 lb in |
| Recirculation Actuator Screws |
1.4 N.m |
12 lb in |
| Temperature Actuator Screws |
1.4 N.m |
12 lb in |
Courtesy of GENERAL MOTORS CORP.
