Removal Procedure

WARNING: This page is about a different car, the 2003 Oldsmobile Aurora. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the rear seat cushion. Refer to SEAT CUSHION REPLACEMENT - REAR .
    CAUTION: Refer to BATTERY DISCONNECT CAUTION .
  2. Disconnect the negative battery cable from the battery.
    Fig 1: Disconnecting Negative Battery Cable From Battery
    G02553223Courtesy of GENERAL MOTORS CORP.
