Endgate Latch Replacement

Fig 1: Latch Replacement - Endgate

Courtesy of GENERAL MOTORS CORP.

Callout	Component Name
NOTE: Refer to Fastener Notice . Fastener Tightening Specifications: Refer to Fastener Tightening Specifications .Preliminary Procedure: Remove the endgate trim panel. Refer to Endgate Trim Panel Replacement .
1	Screws, Latch Assembly (Qty: 3) Tighten: 10 N.m (89 lb in)
2	Latch, Endgate Tip: Disconnect electrical connector.
