Special Tools

Illustration	Tool Number/Description
Courtesy of GENERAL MOTORS CORP.	DT-47847 Front Output Shaft Seal Installer
Courtesy of GENERAL MOTORS CORP.	DT-47946 Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 2619-O1 Slide Hammer
Courtesy of GENERAL MOTORS CORP.	J 3289-20 Holding Fixture
Courtesy of GENERAL MOTORS CORP.	J 6125-1B Slide Hammer with Adapter
Courtesy of GENERAL MOTORS CORP.	J 8614-01 Flange and Pulley Holding Tool
Courtesy of GENERAL MOTORS CORP.	J 22912-B Rear Pinion and Axle Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 23129 Universal Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 23907 Slide Hammer with Bearing Adapter
Courtesy of GENERAL MOTORS CORP.	J 29369-1 Bushing and Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 36850 Transjel Lubricant
Courtesy of GENERAL MOTORS CORP.	J 42176 Universal Driver Handle - Non-Threaded
Courtesy of GENERAL MOTORS CORP.	J 42738 Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45278 Seal Remover
Courtesy of GENERAL MOTORS CORP.	J 45358 Case Spreader
Courtesy of GENERAL MOTORS CORP.	J 45380 Transfer Case Rear Bushing Remover and Installer
Courtesy of GENERAL MOTORS CORP.	J 45548 Mainshaft Support Bushing/Bearing Remover
Courtesy of GENERAL MOTORS CORP.	J 45756 Rear Output Shaft Seal Installer
Courtesy of GENERAL MOTORS CORP.	J 45757 Mainshaft Support Bushing and Bearing Installer
Courtesy of GENERAL MOTORS CORP.	J 45759 Assembly Fixture
