Fuel Line And Vapor Line: Removal
- Raise the vehicle and remove the two fitting nuts while holding the fuel filter nut securely.
CAUTION:
- Reduce the fuel pressure before disconnecting the fuel line and hose, or fuel will spill out.
- Cover the pipe connection with a shop towel to prevent splashing of fuel that could be caused by residual pressure In the fuel line.
- Remove the fuel filter mounting bolts, then remove the fuel filter from the bracket.
Courtesy of HYUNDAI MOTOR CO.
- Remove the fuel return hose and line.
- Remove the fuel vapor hose and line.
