Signal Circuit Inspection

IG "OFF" and disconnect P/S pressure sensor connector and ECM connector.
Measure the resistance between signal terminal of P/S pressure sensor harness connector and chassis ground.
Specification: Approx. 0V

Fig 1: Measuring Resistance Between Signal Terminal Of P/S Pressure Sensor Harness Connector And Chassis Ground
Courtesy of HYUNDAI MOTOR CO.
Is the measured resistance within specification?
YES
- Go to "COMPONENT INSPECTION " procedure.
NO
- Repair short to ground in harness, and go to "VERIFICATION OF VEHICLE REPAIR " procedure.
