Home › Hyundai › 2013 › Sonata GLS › Repair and Diagnosis › External Pages › Different variant/trim › Section 41 (Button Engine Start System (HEV)) › PDM (Power Distribution Module) › Components And Components Location › Component

Components And Components Location: Component

WARNING: This page is about a different variant/trim than selected.
Fig 1: Identifying Power Distribution Module Connector Terminals
G07319393Courtesy of HYUNDAI MOTOR CO.
