RF Receiver

WARNING: This page is about a different car, the 2014 Hyundai Santa Fe Sport and 2013 Hyundai Santa Fe Sport. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: Take care not to scratch the crash pad and related parts.

Disconnect the negative (-) battery terminal.
Remove the crash pad center panel.
Refer to CRACH PAD CENTER PANEL .
Remove the RF receiver after loosening the mounting nut (1EA) and disconnecting the connector.

Fig 1: Identifying Crash Pad Center Panel Connector
Courtesy of HYUNDAI MOTOR AMERICA
