Power Liftgate Inspection With GDS
- Check the power liftgate module input/output value by using the GDS. If the operation of power liftgate module is abnormal, replace power trunk drive unit.
- To check the DTC of the power trunk module, select "PTM"
- Select "Input/output monitoring".
