Chart 7

WARNING: This page is about a different car, the 2017 Hyundai Santa Fe Sport. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Auxiliary Jack Troubleshooting Flow Chart 7
G12054319Courtesy of HYUNDAI MOTOR AMERICA
