Assist Power Window Switch

Fig 1: Assist Power Window Switch Diagram (1 Of 2)
G12036191Courtesy of HYUNDAI MOTOR AMERICA
Fig 2: Assist Power Window Switch Diagram (2 Of 2)
G12036192Courtesy of HYUNDAI MOTOR AMERICA
