Repair Procedures: Inspection

Turn ignition switch OFF and disconnect the negative (-) battery cable.
Remove the console upper cover.
(Refer to Body - "FLOOR CONSOLE ")
Disconnect the connectors (A).

Fig 1: Disconnecting Connectors
Courtesy of HYUNDAI MOTOR AMERICA
Check the continuity between the switch terminals as the DBC switch is engaged.

Fig 2: Checking Continuity Between DBC Switch Terminals

Courtesy of HYUNDAI MOTOR AMERICA
