Engine Mounting Bracket

Remove the engine room under cover.
(Refer to Engine And Transaxle Assembly - "ENGINE ROOM UNDER COVER ")
Install the jack to the edge of lower oil pan to support the engine.
NOTE:
- Insert the rubber block between jack and oil pan.
Remove the engine mounting support bracket (A).
Tightening Torque:

Nut (B):

88.3 - 107.9 N.m (9.0 - 11.0 kgf.m, 65.1 - 79.6 lb-ft)

Bolt (C), Nuts (D):

58.8 - 73.5 N.m (6.0 - 7.5 kgf.m, 43.4 - 54.2 lb-ft)

Courtesy of HYUNDAI MOTOR AMERICA
Remove the Engine Mounting Bracket (A).
Tightening Torque:

49.0 - 63.7 N.m (5.0 - 6.5 kgf.m, 36.2 - 47.0 lb-ft)

Courtesy of HYUNDAI MOTOR AMERICA
Install in the reverse order of removal.
