Repair Procedures: Inspection: Rotor

Check that there is continuity between the slip rings (C).
Check that there is no continuity between the slip rings and the rotor (B) or rotor shaft (A).

Courtesy of HYUNDAI MOTOR AMERICA
If the rotor fails either continuity check, replace the alternator.
