Integrated Thermal Management Module (ITM)
›
Components And Components Location
›
Components
›
Intelligent Variable Transmission (IVT) System
Intelligent Variable Transmission (IVT) System
Fig 1: Intelligent Variable Transmission System Components Location With Torque Specifications
Courtesy of HYUNDAI MOTOR AMERICA
Courtesy of HYUNDAI MOTOR AMERICA
