Repair Procedures: Removal
- Switch "OFF" the ignition and disconnect the battery negative (-) terminal.
- Remove the air duct (A).
(Refer to Engine Mechanical System - "AIR CLEANER ")
- Disconnect the intake air temperature sensor (IATS) connector (A).
- Remove the installation bolts (B), and then remove the sensor from the intake manifold.
Tightening torque: 8.8 - 10.7 N.m (0.9 - 1.1 kgf.m, 6.5 - 7.9 lb-ft)
