Charging System: Alternator

Item	Specification
Type	Alternating current rectification
Rated output	13.5V 150 A
Speed in use	1000 - 18, 000 RPM
Connector pin No.	1 (LIN)
Pulley Type	OAP

Courtesy of HYUNDAI MOTOR AMERICA
