Remote Controller Battery And Function Check

CHECK REMOTE CONTROLLER BATTERY
Remove battery (refer to REMOTE CONTROLLER BATTERY REPLACEMENT ) and measure voltage across battery positive and negative terminals, (+) and (-).

Voltage [V]:

2.5-3.0

NOTE: Remote controller does not function if battery is not set correctly.

Fig 1: Checking Remote Controller Battery

OK or NG
1. OK: GO TO 2.
2. NG: Replace battery.
CHECK REMOTE CONTROLLER FUNCTION
With CONSULT-II

Check remote controller function ("LK BUTTON/SIG", "UN BUTTON/SIG", "PANIC BTN", "UN BUTTON ON" and "LK/UN BTN ON(" in "DATA MONITOR" mode with CONSULT-II.

Fig 2: Checking Remote Controller Function

OK or NG
1. OK: Remote controller is OK. Further inspection is necessary. Refer to "SYMPTOM CHART" in Trouble Diagnoses .
2. NG: Replace remote controller. Refer to ID CODE ENTRY PROCEDURE .
