ICC Sensor

Fig 1: Removal & Installation Of ICC Sensor

Courtesy of NISSAN MOTOR CO., U.S.A.

CAUTION: Adjust the laser beam aiming every time the ICC sensor is removed or installed.

Tighten bolts to specification. See TORQUE SPECIFICATIONS .
