Notes
Removal And Installation: Notes
Fig 1: Identifying Connector Terminal
Courtesy of NISSAN MOTOR CO., U.S.A.
NOTE:
Exhaust control valve is provided in center muffler and not permitted to disassemble.
Courtesy of NISSAN MOTOR CO., U.S.A.
