ASCD Steering Switch

  1. Disconnect combination switch (spiral cable) harness connector.
  2. Check continuity between combination switch (spiral cable) terminals 14 and 15 with pushing each switch.
    Fig 1: Continuity Between Terminals Chart
    G02360992Courtesy of NISSAN MOTOR CO., U.S.A.
    Fig 2: Checking Continuity Between Combination Switch (Spiral Cable) Terminals 14 And 15
    G02360993Courtesy of NISSAN MOTOR CO., U.S.A.
