BCM (Body Control Module): Schematic

Fig 1: Identifying CAN Communication Schematic Chart (1 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.

Fig 2: Identifying CAN Communication Schematic Chart (2 Of 2)

Courtesy of NISSAN MOTOR CO., U.S.A.
