Intake Valve Timing Control Solenoid Valve (RH): Removal

  1. Remove drive belt. Refer to "REMOVAL AND INSTALLATION ".
  2. Disconnect Intake valve timing control solenoid valve connector (RH).
  3. Remove Intake valve timing control solenoid valve (RH) (3) from Intake valve timing control solenoid valve cover (RH) (1).
    Fig 1: Identifying Intake Valve Timing Control Solenoid Valve And Cover (RH)
    G06315982Courtesy of NISSAN MOTOR CO., U.S.A.
