2WD: Exploded View: Disassembly

Fig 1: Disassembled View Of Alternator With Torque Specifications (Type A003TJ1991)

Courtesy of NISSAN NORTH AMERICA, INC.

Refer to "COMPONENTS " for symbols in the figure.
