2WD Models

WARNING: This page is about a different car, the 2008 Infiniti EX35. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Cross-Sectional View Of Shift Mechanism - 2WD Models

Courtesy of NISSAN MOTOR CO., U.S.A.
