DTC Inspection Priority Chart
WARNING: This page is about a different car, the 2011 Nissan Leaf. However, it is still accessible from the selected car via links, so may be relevant.
If some DTCs are displayed at the same time, perform inspections one by one based on the priority as per the following list.
DTC INSPECTION PRIORITY CHART
| Priority | Detected items (DTC) | Reference |
|---|---|---|
| 1 | P0706 TRANSMISSION RANGE SENSOR A | Figure |
| P0780 SHIFT ERROR | P0780 SHIFT ERROR | |
| P1802 CONTROL MODULE | P1802 CONTROL MODULE | |
| P1803 CONTROL MODULE | P1803 CONTROL MODULE | |
| P1897 ENCODER ERROR | P1897 ENCODER ERROR | |
| P189E ACTUATOR LOCK | P189E ACTUATOR LOCK | |
| P18A3 CONTROL MODULE | P18A3 CONTROL MODULE | |
| P18A4 CONTROL MODULE | P18A4 CONTROL MODULE | |
| P18A7 SHIFT SIGNAL OFF | P18A7 SHIFT SIGNAL OFF | |
| P18A8 P POSITION SWITCH | P18A8 P POSITION SWITCH | |
| P18A9 PARKING ACTUATOR FUNCTION | P18A9 PARKING ACTUATOR FUNCTION | |
| P18AA P POSITION LEARNING ERROR | P18AA P POSITION LEARNING ERROR | |
| P18AB IGNITION SWITCH | P18AB IGNITION SWITCH | |
| 2 | P0571 BRAKE SWITCH A | DTC/CIRCUIT DIAGNOSIS |
| P0705 TRANSMISSION RANGE SENSOR A | P0705 TRANSMISSION RANGE SENSOR A | |
| P1722 VEHICLE SPEED | P1722 VEHICLE SPEED | |
| P1804 CONTROL MODULE | P1804 CONTROL MODULE | |
| P1811 ELECTRIC SHIFT POWER SUPPLY RELAY | P1811 ELECTRIC SHIFT POWER SUPPLY RELAY | |
| P1895 MOTOR SPEED | P1895 MOTOR SPEED | |
| P1896 SHIFT POWER SUPPLY | P1896 SHIFT POWER SUPPLY | |
| P1899 MOTOR A | P1899 MOTOR A | |
| P189A MOTOR A | P189A MOTOR A | |
| P189B MOTOR B | P189B MOTOR B | |
| P189C MOTOR B | P189C MOTOR B | |
| P189D BACK UP VOLTAGE | P189D BACK UP VOLTAGE | |
| P189F ANGLE SENSOR 1 | P189F ANGLE SENSOR 1 | |
| P18A0 ANGLE SENSOR 2 | P18A0 ANGLE SENSOR 2 | |
| P18A1 ANGLE SENSOR 1 | P18A1 ANGLE SENSOR 1 | |
| P18A2 ANGLE SENSOR 2 | P18A2 ANGLE SENSOR 2 | |
| P18A6 WAKE UP SIGNAL | P18A6 WAKE UP SIGNAL | |
| P18AC PARKING ACTUATOR RELAY A | P18AC PARKING ACTUATOR RELAY A | |
| P18AD PARKING ACTUATOR RELAY B | P18AD PARKING ACTUATOR RELAY B | |
| P18AE STUCK IN SHIFT | P18AE STUCK IN SHIFT | |
| U1000 CAN COMM CIRC | U1000 CAN COMM CIRCUIT | |
| U1010 CONTROL UNIT (CAN) | U1010 CONTROL UNIT (CAN) | |
| U1086 CAN ERROR | U1086 CAN ERROR |
