Component Parts Location

WARNING: This page is about a different variant/trim than selected.

Fig 1: Vehicle Security System Component Parts Location (1 Of 2)

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 2: Vehicle Security System Component Parts Location (2 Of 2)

Courtesy of NISSAN NORTH AMERICA, INC.
