Exploded View

WARNING: This page is about a different variant/trim than selected.

Fig 1: Exploded View Of Main Drive Gear

G08740006

Courtesy of NISSAN NORTH AMERICA, INC.

Refer to "COMPONENTS " for symbols not described on the above.

Apply gear oil to gears, shafts, synchronizers, and bearings when assembling.
