Engine Lubrication System Schematic

Fig 1: ENGINE OIL COOLER AIR COOLING TYPE

Courtesy of NISSAN NORTH AMERICA, INC.

Fig 2: ENGINE OIL COOLER WATER COOLING TYPE

Courtesy of NISSAN NORTH AMERICA, INC.
