Exploded View

Fig 1: Exhaust System Components With Torque Specifications

GNSAWBIA0271Z-271

Courtesy of NISSAN NORTH AMERICA, INC.

1.	Exhaust gasket	2.	Mounting rubber	3.	Front exhaust tube assembly
4.	Exhaust gasket	5.	Oxygen sensor	6.	Main muffler assembly
7.	Mounting rubber	8.	Mounting rubber
